Type	Stereo & Integrated	Stereo & Integrated	Stereo & Integrated	Stereo & Integrated	Stereo & Integrated	Mono-Block	Mono-Block
Power	2 x 12 Watts Class A into 8 Ohms	2 x 12 Watts Class A into 8 Ohms	2 x 18 Watts Class A into 8 Ohms	2 x 24 Watts Class A into 8 Ohms	2 x 25 Watts Class A into 8 Ohms	2 x 30 Watts Class A into 8 Ohms	2 x 45 Watts Class A into 8 Ohms
Distortion @ 1 Watt	<0.1% No Feedback	” “	” “	” “	” “	” “	” “
Sensitivity	Variable >200mV Full Output	” “	” “	” “	” “	” “	” “
Consumption	130 Watts	140 Watts	160 Watts	175 Watts	185 Watts	320 Watts	320 Watts
Load	8 Ohm Nominal	” “	” “	” “	” “	4 & 8 Ohm Nominal	4 & 8 Ohm Nominal
Frequency Response	14Hz to 34KHz ± 1db	12Hz to >40KHz ± 1db	<10Hz to >40KHz ± 1db	<10Hz to >40KHz ± 1db	<10Hz to >40KHz ± 1db	<10Hz to >40KHz ± 1db	<10Hz to >40KHz ± 1db
Noise	< (CCIR) -85db	” “	” “	” “	” “	” “	” “
Valves	2 x EL34, 1 x 6H23N, 1 x 5687	2 x EL34, 2 x 6H23N	2 x KT88, 2 x 6H23N	2 x KT120, 2 x 6H23N	2 x KT150, 2 x 6H23N	4 x KT88, 4 x 6H23N	4 x KT88, 4 x 6H23N
Size Height, Width, Depth.	19cm, 23cm, 42cm,	” “	” “	” “	” “	19cm, 23cm, 42cm, each Mono	19cm, 23cm, 42cm, each Mono
Weight	11Kg	14Kg	” “	” “	” “	14Kg each Mono	14Kg each Mono
Fuses Power	240V 2A 120V 3.5A Slow Blow	” “	” “	” “	” “	” ” each Mono	” ” each Mono
Fuses HT	240V 0.5A 120V 1A Slow Blow	” “	” “	” “	” “	” ” each Mono	” ” each Mono
Input Impedance	50K ohms.	” “	” “	” “	” “	” “	” “
Warranty.	2 Years – Tubes 6 Months	” “	” “	” “	” “	” “	” “
