Format	2-channel D/A converter
Supported sampling frequencies	USB input (PCM) : 32k, 44.1k, 48k, 88.2k 96k, 176.4k, 192k(16, 24, 32bits) USB input (DSD) : 2.82M, 5.64MHz (1bit) COAX/OPT input : 32k, 44.1k, 48k, 88.2k 96k, 176.4k, 192kHz (16, 20, 24bits) MC HIGH: 0.37mV, MC LOW: 0.12mV
Digital input	USB x 1, COAX x 1, OPT x 2
Digital output	COAX x 1, OPT x 1
Analog input	Unbalance x 1
Analog output	Unbalance x 1, Balance x 1, Headphone x 1
Line output voltage/imipedance	Unbalance : 2.5V/300Ω, Balance : 2.5V/600Ω

Headphone output	130mW + 130mW(600Ω) 400mW + 400mW(32Ω), 200mW + 200mW(16Ω)
Frequency response	2Hz to 50kHz (+0, -3.0dB)
Total harmonic distortion	0.001%
S/N ratio (IHF-A)	118dB
Power supply	230V~(50Hz) / 115V~(60Hz)
Power consumption	20W
Dimensions	364(W) x 81(H) x 279(D) mm front side knob of 14mm and rear side terminal of 8mm included in depth
Net weight	5.4kg(main unit)
Accessories	Remote control (RD-24) Power cable
