Specifications
Track system: 8-track, 8-channel system
Heads: 1 x record/playback, 1 x erase
Motor: 1 x capstan, 2 x reel, 1 x loading
Reel size: up to 7 inch reel
Equalization: IEC-1
Tape speeds: 15 ips
Wow and flutter: 0.08% (15 ips)
Frequency response: 45Hz to 18kHz (15 ips)
Signal to Noise Ratio: 78dB
Total harmonic distortion: 1%
Input: 300mV (line)
Output: 0.3V (line)
Dimensions: 328 x 316 x 173mm
Weight: 10kg
Year: 1988
