    90 watt per canale su 6 Ohm / 72 watt in 8ohms
    Alta specifica stadio phono integrato
    Alimentatori avanzati per la fase pilota
    Ibrido del disegno Brio-R e Elicit-R
    Dedicato mini telecomando incluso
    Pre-amp out / Record Out / 4 ingressi di linea
    Nuovo trasformatore personalizzato

Specifications

    Power Supply
    Voltage: 230v & 115v
    Frequency: 60/60Hz
    Power Consumption: 250 Watts
    230v Fuse: T3.15AL 20mm
    115v Fuse: T5AL 20mm
    Dimensions W 430mm x D 320mm x H 80mm

Output power

    72.5W 8Ω both channels driven - Design centre rating
    90W 6Ω both channels driven - Rega speaker impedance rating
    113W 4Ω both channels driven

Phono input

    Sensitivity (72.5W 8Ω1.7mV (Load 47K in parallel with 220pF)
    Maximum input level: 100mV

Line input

    Sensitivity (72.5W 8Ω 164mv (Load 30-50K)
    Maximum input level: 10v

Tape output

    Level: 164mV with rated input
    Output impedance: 470

Line output

    Level: 625mV with rated input
    Output impedance: 6
