Data:
General
- Manufacturer: Denon
- Model: DP-59 L
- Type: Record player
- Years of manufacture: 1986 - 1992
- Made in: Japan
- Color: Silver / Black, frame in rosewood (replica)
- Power consumption: 10 W
- Dimensions: 490 x 219 x 410 mm (WxHxD)
- Weight: 15 kg
- Original price approx.: 1'400 DM
Specifications
- Drive: Servo Controlled Direct Drive
- Speed: 33 1/3 / 45
- speed deviation: < 0,002%
- Speed fine adjustment: ± 9.9% quartz stabilized
- Synchronous speed variation: < 0.006% WRMS
- Rumble noise ratio: 82 dB (DIN B)
- Turntable: Die-cast aluminium, 7 mm thick, 2.2 kg, 325 mm diameter
- Tonearm
Design: Straight, statically balanced (S-shaped tonearm optional)
-
- Needle overhang: 14 mm
- tangential tracking error angle: < 2.5°
- adjustable support weight: 0 - 3 g
- system carrier: PCL-59
- anti-skating device: ground terminal
Special Features
- microprocessor-controlled contactless "Dynamic Servo Tracer" tonearm with Q-damping
- massive turntable (2,2 kg) driven by servo motor with high torque
- quartz stabilized fine speed control
- LED illumination, LCD display, pitch control
